Description
| Model |
D3032x10 |
D3040x10 |
| Max. Drilling capacity (mm) |
32 |
40 |
| Distance spindle axis to column generating line (mm) |
200-1000 |
200-1000 |
| Diameter of column (mm) |
240 |
240 |
| Spindle taper |
MT4 |
MT4 |
| Spindle travel (mm) |
250 |
250 |
| Spindle speeds range (r/min) |
71-1800 |
71-1800 |
| Spindle speeds series |
8 |
8 |
| Range of Spindle feeds (mm/r) |
0.13-0.54 |
0.13-0.54 |
| Spindle feeds |
4 |
4 |
| Distance spindle nose to working surface of base (mm) |
264-1064 |
264-1064 |
| Dimension of worktable (mm) |
400 X 450 X 400 |
400 X 450 X 400 |
| Dimension of base (mm) |
1500 X 740 X 160 |
1500 X 740 X 160 |
| Overall size (mm) |
1730 X 750 X 2360 |
1730 X 750 X 2360 |
| Power of Main motor (KW) |
2.2 |
3 |
| G.W/N.W (kg) |
1600/1530 |
1600/1530 |
| Packing dimension (cm) |
187 X 97 X 220 |
187 X 97 X 220 |
PURROS Machinery have various types of Hydro Speed Regulators, Self-Feeding Drill Heads(Units), Multi-Spindle Drill Heads and Servo feed tapping machine, Special Purpose Machines, warmly waiting for you to inquire.
