Description
| Model |
DMT4625 |
DT5032 |
| Max. Drilling capacity (mm) |
25 |
40 |
| Max. Tapping capacity (mm) |
M24/M20 |
M32 |
| Max. Face Mill Capacity (mm) |
63 |
/ |
| Diameter of vertical milling (mm) |
13 |
/ |
| Spindle travel (mm) |
125/110 |
65/110 |
| Head travel (mm) |
440 |
750 |
| Distance spindle axis to column generating line (mm) |
240 |
261.5 |
| Distance column (mm) |
280 |
500 |
| Dimension spindle nose to worktable (mm) |
75-510 |
500 |
| Spindle taper |
MT3 |
MT3/MT4 |
| Spindle speeds range (r/min) |
290-2150 |
80-280/50-1250 |
| Spindle speeds series |
5 |
3/6 |
| Dimension of worktable surface (mm) |
640 X 205 |
1100 X 280 |
| Dimension of base (mm) |
650 X 600 |
1100 X 690 |
| Table travel (mm) |
370 X 150 |
500 |
| Overall height (mm) |
1130 |
2000 |
| Motor (KW) |
0.75(6P) |
1.5/1.1 |
| G.W/N.W (kg) |
320/280 |
850/800 |
| Packing dimension (cm) |
93 X 85 X 105 |
132 X 105 X 230 |
PURROS Machinery have various types of Hydro Speed Regulators, Self-Feeding Drill Heads(Units), Multi-Spindle Drill Heads and Servo feed tapping machine, Special Purpose Machines, warmly waiting for you to inquire.
